Xinje DS2 series Manual

28
D-
+24V
5
D+5V
5V difference
input
12
SO1
Output terminal 1
6
D+24V
Open collector
input
13
SO2
Output terminal 2
7
SI1
Input terminal 1
14
COM
Ground of output
terminal
 CN1（DB15）terminals
No.
Name
Contents
No.
Name
Contents
1
NC
Reservation
9
Z-
Encoder output
Z-
2
NC
Reservation
10
B+
Encoder output
B+
3
SI5
Input terminal 5
11
T-REF
Torque analog
input
4
SO3
Output terminal 3
12
V-REF
Speed analog
input
5
B-
Encoder output B-
13
GND
GND for analog
input
6
A+
Encoder output A+
14
A
RS485
communication+
7
A-
Encoder output A-
15
B
RS485
communication -
8
Z+
Encoder output Z+
