3 Product Description
3.1 Products included
Pump model Standard EX MSHA Drainage Sludge
2190.010 X X
2201.012 X X
2201.020 X X
2201.320 X X
2201.590 X X X
2201.690 X X
2201.691 X X
3.2 Pump design
The pump is submersible, and driven by an electric motor.
Intended use
The product is intended for moving waste water, sludge, raw and clean water. Always
follow the limits given in Application limits (page 59). If there is a question regarding the
intended use of the equipment, please contact a local sales and service representative
before proceeding.
DANGER: Explosion/Fire Hazard
Special rules apply to installations in explosive or flammable atmospheres. Do not install
the product or any auxiliary equipment in an explosive zone unless it is rated explosion-
proof or intrinsically-safe. If the product is EN/ATEX-, MSHA- or FM-approved, then see
the specific EX information in the Safety chapter before taking any further actions.
NOTICE:
Do NOT use the unit in highly corrosive liquids.
For information about pH, see Application limits (page 59).
Particle size
The pump can handle liquid containing particles that correspond to the holes in the
strainer.
Product version Number of holes Hole dimensions
2201.012 HT/SH
2190.010 HT
541 Diameter 12 mm (0.47 in)
2201.012 MT
2201.020 LT
656 Diameter 15 mm (0.59 in)
2201.320 LT/MT
2201.590 LT/MT
2201.690 LT/MT
2201.691 LT/MT
212 10×10 mm (0.4×0.4 in)
2201.320 HT
2201.590 HT
2201.690 HT
2201.691 HT
574 15×45 mm (0.6×1.77 in)
3 Product Description
10 Flygt 2190, 2201 Installation, Operation, and Maintenance Manual
