6.4.8 Install the impeller, alternative 4
Table 10: Applicability
Product code Pressure class Open or closed impeller
2190.010 HT Open
2201.012 MT, HT Open
1. Prepare the shaft:
a) Polish off any flaws with a fine emery cloth.
The end of the shaft must be clean and free from burrs.
b) Coat the inner conic, the outer cylindrical surfaces, and the thread of the conical
sleeve with a thin layer of grease.
The proper lubrication is grease for bearings, for example Exxon Mobil Unirex N3,
Mobil Mobilith SHC 220 or equivalent.
NOTICE:
Surplus grease can cause the impeller to become loose. Remove surplus grease
from conical and/or cylindrical surfaces of shafts and/or sleeves.
2. Align the edge of the adjustment screw with the edge of the conical sleeve so that
they are flush.
6 Maintenance
50 Flygt 2190, 2201 Installation, Operation, and Maintenance Manual
