INTERNET CONNECTION FEATURE
Yaesu FT-8800R Operating Manual (courtesy of W5JCK) Page 62 of 83
4. Rotate the DIAL knob to select Menu #17 INET.
5. Press the DIAL knob momentarily, then rotate the DIAL knob to set this
Item to INT.MEM (to enable the alternative Internet Link, and disable the WIRES™
access option).
6. Press and hold in the DIAL knob for ½ second to save the new setting and exit to
normal operation.
7. Press the left VOL knob momentarily to activate the Internet Link System. INT ON
will be displayed for 2 seconds in the Main band frequency field. The int icon will
then be displayed in the memory channel field on the Sub band while the Internet
Link System access feature is engaged.
8. Rotate the DIAL knob, while pressing and holding in the left VOL knob, to select
the DTMF access number (IMEM 1 through IMEM16) corresponding to the Internet Link
repeater to which you wish to establish an Internet Link.
9. With the Internet Link feature activated, press the left VOL knob, or microphone’s
key, to send out the DTMF tones according to your selection in step 8 (to
establish the link to the Internet Link repeater).
10. To disable the Internet Link feature, press the left VOL knob again. 0.
To return to WIRES™, recall Menu #17 INET, then set it to INT. COD.
