Page 127FTDX5000 OPERATING MANUAL
063 A1A BK-IN
Function: Sets the CW “break-in” mode.
Available Values: SEMI / FULL
Default Setting: SEMI
SEMI: The transceiver will operate in the semi break-
in mode. The delay (receiver recovery) time is
set by the front panel
[
DELAY
]
knob.
FULL: The transceiver will operate in the full break-
in (QSK) mode.
064 A1A SHAPE
Function: Selects the CW carrier wave-form shape (rise/
fall times).
Available Values: 1ms / 2ms / 4ms / 6ms
Default Setting: 4 ms
065 A1A WEIGHT
Function: Sets the Dot:Dash ratio for the built-in elec-
tronic keyer.
Available Values: (1:) 2.5 ~ 4.5
Default Setting: 3.0
066 A1A FRQ DISP
Function: Selects the frequency Display Format for the
CW mode.
Available Values: FREQ / PITCH
Default Setting: PITCH
FREQ: Displays the receiver carrier frequency, with-
out any offset added. When changing modes
between SSB and CW, the frequency display
remains constant.
PITCH: This frequency display reflects the added
BFO offset.
067 A1A PC KYNG
Function: Enables/disables CW keying from the
“PACKET PTT” terminal (pin 3) on the rear panel’s
PACKET jack while operating in the CW mode.
Available Values: DISABLE / ENABLE
Default Setting: DISABLE
068 A1A QSK TIME
Function: Selects the time delay between when the PTT
is keyed and the carrier is transmitted during QSK opera-
tion when using the internal keyer.
Available Values: 15ms / 20ms / 25ms / 30 ms
Default Setting: 15ms
MODE-DAT GROUP
069 DATA DATA IN
Function: Selects the data input path to be used in the
PKT mode.
Available Values: DATA / PC
Default Setting: DATA
DATA: Uses the data input line connected to pin 1 of
the PACKET jack while using the PKT mode.
PC: This parameter is for future expansion of this
transceiver’s capabilities, but at this time is
not supported.
070 DATA DT GAIN
Function: Sets the data input level from the TNC to the
AFSK modulator.
Available Values: 0 ~ 100
Default Setting: 50
071 DATA DT OUT
Function: Selects the receiver to be connected to the data
output port (pin 4) of the PACKET jack.
Available Values: VFO-A / VFO-B
Default Setting: VFO-A
072 DATA OUT LVL
Function: Sets the AFSK data output level at the output
port (pin 4) of the PACKET jack.
Available Values: 0 ~ 100
Default Setting: 50
073 DATA VOX DLY
Function: Adjusts the “VOX” delay (receiver recovery)
time in the PKT mode.
Available Values: 30ms ~ 3000ms (10 ms/step)
Default Setting: 300ms
074 DATA VOX GAIN
Function: Adjusts the “VOX” gain in the PKT mode.
Available Values: 0 ~ 100
Default Setting: 50
MODE-CW GROUP
MENU MODE
