8-20
8
7. Check the differential gear case for oil leak-
age. If oil is leaking, check for the cause.
EBU23671
Cleaning the air filter element
The air filter element should be cleaned at the in-
tervals specified in the periodic maintenance and
lubrication chart. Clean the air filter element more
frequently if you are riding in unusually wet or dusty
areas.
NOTE:
There is a check hose at the bottom of the air filter
case. If dust or water collects in this hose, empty
the hose and clean the air filter element and air fil-
ter case.
1. Remove the seat. (See page 4-19.)
2. Remove the air filter case cover by unhooking
the holders.
Tightening torque:
Differential gear oil filler bolt:
23 Nm (2.3 m·kgf, 17 ft·lbf)
1. Air filter case check hose
U4S110E0.book Page 20 Friday, August 4, 2006 4:03 PM
