5-1
5
EBU19200
PRE-OPERATION CHECKS
EBU19210
Pre-operation check list
Before operating this ATV, be sure to check the items listed in the following table.
NOTE:
The maintenance of some items in the table has to be performed by a Yamaha dealer. Refer to the “Periodic
maintenance and lubrication chart” on page 8-3 to determine which service should be performed by a
Yamaha dealer.
ITEM ROUTINE PAGE
Fuel
• Check fuel level in fuel tank, and add recommended fuel if neces-
sary.
• Check fuel line for leakage. Correct if necessary.
4-16, 5-3
Engine oil
• Check oil level in engine, and add recommended oil to specified lev-
el if necessary.
• Check ATV for oil leakage. Correct if necessary.
5-3, 8-11
Final gear oil • Check ATV for oil leakage. Correct if necessary. 5-3, 8-15
Differential gear oil • Check ATV for oil leakage. Correct if necessary. 5-3, 8-17
Front brake
• Check operation. If soft or spongy, have Yamaha dealer bleed hy-
draulic system.
• Check brake pads for wear, and replace if necessary.
• Check brake fluid level in reservoir, and add recommended brake
fluid to specified level if necessary.
• Check hydraulic system for leakage. Correct if necessary.
5-3, 8-27, 8-28, 8-29
Rear brake
• Check operation, and correct if necessary.
• Lubricate cables if necessary.
• Check lever and pedal free play, and adjust if necessary.
5-3, 8-27, 8-30
