AUTO SETUP
MANUAL SETUP
SIGNAL INFO
1 SOUND MENU
2 INPUT MENU
3 OPTION MENU
(RX-V661: U, C, R, T,
K, A, G, E, L models /
HTR-6060: G model)
(U, C models)
A) SPEAKER SET
B) SPEAKER LEVEL
C) SP DISTANCE
D) EQUALIZER
E) LFE LEVEL
F) DYNAMIC RANGE
G) AUDIO SET
(J model)
H) HDMI SET
I) EXTD SURROUND
A) I/O ASSIGN
B) INPUT RENAME
C) VOLUME TRIM
D) DECODER MODE
E) MULTI CH SET
A) DISPLAY SET
B) MEMORY GUARD
C) AUDIO SELECT
D) PARAM. INI
E) ZONE 2 SET
F) XM RADIO SET
G) DOCK SET
EXTRA SP ASSIGN : FRONT B
FRONT B : FRONT
PRIORITY : SUR.B
FRONT SP : LARGE
CENTER SP : SML
SUR. L/R SP : SML
SUR. B L/R SP : SMLx2
LFE/BASS OUT : BOTH
CROSS OVER : 80Hz
SUBWOOFER PHASE: NORMAL
FL • • • • • || • • • • •
FR • • • • • || • • • • •
C • • • • • || • • • • •
SWFR • • • • • || • • • • •
SL • • • • • || • • • • •
SR • • • • • || • • • • •
SBR • • • • • || • • • • •
SBL • • • • • || • • • • •
PL • • • • • || • • • • •
PR • • • • • || • • • • •
UNIT : feet
FRONT L : 10.0ft
FRONT R : 10.0ft
CENTER : 10.0ft
SWFR : 10.0ft
SUR. L : 10.0ft
SUR. R : 10.0ft
SB L : 7.0ft
SB R : 7.0ft
PRNS L : 10.0ft
PRNS R : 10.0ft
FRONT L : 3.00m
FRONT R : 3.00m
CENTER : 3.00m
SWFR : 3.00m
SUR. L : 3.00m
SUR. R : 3.00m
SB L : 2.10m
SB R : 2.10m
PRNS L : 3.00m
PRNS R : 3.00m
EQ TYPE SELECT : CENTER GEQ
TEST : >OFF ON
100Hz – – || – – 0dB
300Hz – – || – – 0dB
1kHz – – || – – 0dB
3kHz – – || – – 0dB
10kHz – – || – – 0dB
SPEAKER : 0dB
HEADPHONE : 0dB
SP D. R. : MAX
HP D. R. : MAX
MUTE TYPE : FULL
A. DELAY : 0 ms
MAX VOL. : +16.5dB
INI. VOL. : OFF
DUAL MONO : MAIN
SUPPORT AUDIO : RX-V661
MODE : AUTO
TYPE : PLIIx Movie
CMPNT-V INPUT [A] : DVD
CMPNT-V INPUT [B] : DTV/CBL
CMPNT-V INPUT [C] : DVR
OPTICAL OUT (1) : MD/CD-R
COAXIAL IN (2) : MD/CD-R
OPTICAL IN (3) : DVD
OPTICAL IN (4) : DTV/CBL
COAXIAL IN (5) : CD
COAXIAL IN (6) : DVD
HDMI IN (IN1) : DVD
HDMI IN (IN2) : DTV/CBL
CD / MD/CD-R / DVD / DTV/CBL / V-AUX /
DVR
BGV : LAST
INPUT CH : 6CH
FRONT : DVD
DIMMER : 0
VIDEO CONVERSION : ON
OSD SHIFT : 0
OSD-SOURCE : 30s
OSD-AMP : 30s
FL SCROLL : CONT
MEMORY GUARD : OFF
: AUTO
MAX VOL. : +16.5dB
INI. VOL. : OFF
XM ANTENNA : NONE
: AUTO
[FRONT B] / ZONE2 / PRESENCE / NONE
[FRONT] / ZONE B
PRNS / [SUR. B]
SMALL / [LARGE]
NONE / [SML] / LRG
NONE / [SML] / LRG
NONE / SMLx1 / [SMLx2] / LRGx1 / LRGx2
SWFR / FRONT / [BOTH]
40 / 60 / [80] / 100 / 110 / 120 / 160 / 200 Hz
[NORMAL] / REVERSE
-10 dB to +10 dB [CENTER (0)], 1 dB step
feet / meters
feet: 1.0 to 80.0 ft [10.0 ft], 0.5 ft step
meters: 0.30 to 24.00 m [3.00 m], 0.10 m step
AUTO PEQ / [CENTER GEQ] / EQ OFF
[OFF] / ON
-6 dB to +6 dB [0 dB], 0.5 dB step
-20 dB to 0 dB [0 dB], 1 dB step
-20 dB to 0 dB [0 dB], 1 dB step
MIN / STD / [MAX]
MIN / STD / [MAX]
[FULL] / -20 dB
[0 ms] to 160 ms, 1 ms step
[+16.5 dB] / +10.0 dB / +5.0 dB / 0 dB / -5.0 dB / -10.0 dB / -15.0 dB / -20.0 dB / -25.0 dB / -30.0 dB
[OFF] / -80.0 dB to +16.5 dB, 0.5 dB step
[MAIN] / SUB / ALL
[RX-V661] (U, C, R, T, K, A, G, E, L models) / [DSP-AX761] (B, J models) / OTHER
[AUTO] / ON / OFF
[PLIIx Movie] / PLIIx Music / EX/ES / EX
[DVD] / DTV/CBL / V-AUX / DVR / VCR
DVD / [DTV/CBL] / V-AUX / DVR / VCR
DVD / DTV/CBL / V-AUX / [DVR] / VCR
PHONO / CD / [MD/CD-R] / DVD / DTV/CBL / V-AUX / VCR / DVR
PHONO / CD / MD/CD-R / [DVD] / DTV/CBL / V-AUX / VCR / DVR
PHONO / CD / MD/CD-R / DVD / [DTV/CBL] / V-AUX / VCR / DVR
PHONO / [CD] / MD/CD-R / DVD / DTV/CBL / V-AUX / VCR / DVR
PHONO / CD / MD/CD-R / [DVD] / DTV/CBL / V-AUX / VCR / DVR
PHONO / CD / [MD/CD-R] / DVD / DTV/CBL / V-AUX / VCR / DVR
[DVD] / DTV/CBL / V-AUX / DVR / VCR
DVD / [DTV/CBL] / V-AUX / DVR / VCR
XM (U, C models) / TUNER / PHONO /CD / MD/CD-R / DVD / DTV/CBL / VCR / DVR / V-AUX / DOCK /
MULTI CH
Input is possible to 8 characters / 8文字まで入力可能
Input possible Character type / 入力可能文字: Capital / 英大文字 “A to Z”, Small / 英小文字 “a to z”, Figure
/ 数字 “0 to 9”, Space / 空白, Marks / 記号 “# * + , - . / : < > ?”
XM (U, C models) / TUNER / PHONO /CD / MD/CD-R / DVD / DTV/CBL / VCR / DVR / V-AUX / DOCK /
MULTI CH
-6.0 dB to +6.0 dB, [0.0 dB], 1 dB step
[AUTO] / LAST
[AUTO] / DTS / AAC (J model)
DVD / DTV/CBL / V-AUX / DVR / VCR / [LAST] / OFF
[6CH] / 8CH
CD / MD/CD-R / [DVD] / DTV/CBL / V-AUX / DVR / VCR
-4 to [0], 1 step
[ON] / OFF
-5 to +5, [0], 1step
10 s / [30 s] / OFF
10 s / [30 s] / OFF
[CONT] / ONCE
[OFF] / ON
[AUTO] / LAST
CLASSICAL / LIVE/CLUB / ENTERTAINMENT / MOVIE / STEREO / SUR. DECODE / ENHANCER
[+16.5 dB] / +10.0 dB / +5.0 dB / 0 dB / -5.0 dB / -10.0 dB / -15.0 dB / -20.0 dB / -25.0 dB / -30.0 dB
[OFF] / -80.0 dB to +16.5 dB, 0.5 dB step
[NONE] / 0 % to 100 %, 1 % step
[AUTO] / OFF
• SET MENU TABLE / セットメニュー
CATEGORY MAIN MENU SUB MENU SELECT MENU
VALUE [INITIAL]
1 FORMAT (Signal format)
2 SAMPLING
3 CHANNEL
4 BITRATE (Bit rate)
5 FLAG
Use this feature to automatically adjust speaker and system parameters.
本機に搭載の「YPAO」により、お使いになるスピーカーの配置や性能、お部屋の音響特性を測定し、最適な視聴空間を自動的に設定します。
Analog / PCM / DolbyD / DTS / AAC (J model) / Digital / --- / ???
xxx kHz
3/2/0.1 (Front/Surround/LFE) / 1+1
xxx kbps
DolbyD / DTS / PCM / None
