Yamaha DSP-AX861 User Manual

38
RX-V861/HTR-6080/DSP-AX861SE/DSP-AX861
RX-V861/HTR-6080/DSP-AX861SE/
DSP-AX861
4.FRNT:SML 0dB
FRONT: SML 0dB
90 Hz or lower signal is mixed to the channel specified by LFE/BASS and output.
90Hz以下の信号がLFE/BASSで指定したチャンネルにミックスされて出力します。
CENTER: NONE
The CENTER signal is assigned to FRONT L/R.
CENTERの信号をFRONTL/Rに振り分け出力します。
LFE / BASS: FRONT
The LFE/BASS signal is assigned to FRONT L/R.
LFE/BASSの信号をFRONTL/Rに振り分け出力します。
PRESENCE Mix-P
The PRESENCE L/R signal is increased by 6.0 dB and assigned to FRONT L/R.
PRESENCEL/Rの信号が+6.0dBされてFRONTL/Rに振り分け出力します。
PRESENCE Mix-F
The FRONT L/R signal is increased by 6.0 dB and output.
FRONTL/Rの信号が+6.0dBされて出力します。
Zone2 Amp (EXTRA SP) ON
The ZONE2 L/R (EXTRA SP L/R) signal is output.
EXTRASPL/Rの信号を出力します。
Bi-AMP
The Bi-AMP signal is output.
Bi-AMPの信号を出力します。
TONE: MAX
The signal is output with tone control of “BASS +10 dB” and “TREBLE +10 dB”.
トーンコントロールBASS+10dB、TREBLE+10dBで出力します。
TONE: MIN
The signal is output with tone control of “BASS -10 dB” and “TREBLE -10 dB”.
トーンコントロールBASS-10dB、TREBLE-10dBで出力します。
4.CENTER:NONE
4.LFE/B:FRNT
4.Pres Mix-P
4.Pres Mix-F
4.Zone2 Amp ON
4.Bi-Amp
4.TONE:MAX
4.TONE:MIN
SURROUND
BACK L/R
Input level Volume
SPEAKER OUT
SUBWOOFER
OUTPUT
INPUT: DVD ANALOG
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
FRONT L/R CENTER
SURROUND
L/R
Sub-menu
(*) ZONE2 L/R (EXTRA SP L/R) SPEAKER OUT: +12.0 dBm
FRNT : SML 0dB
CENTER : NONE
LFE/B : FRNT (50 Hz)
Pres Mix-P
Pres Mix-F
Zone2 Amp ON
Bi-AMP
TONE : MAX
TONE : MIN
Both ch, -20 dBm
Both ch, -20 dBm
Both ch, -20 dBm
Both ch, -20 dBm
Both ch, -20 dBm
Both ch, -20 dBm
Both ch, -20 dBm
Both ch, -20 dBm
Both ch, -20 dBm
+6.0 dB
+6.0 dB
+6.0 dB
+6.0 dB
+6.0 dB
+6.0 dB
+6.0 dB
+6.0 dB
+6.0 dB
+12.0 dBm
-∞
+3.0 dBm
+12.0 dBm
+12.0 dBm
+12.0 dBm
+12.0 dBm
+12.0 dBm
+12.0 dBm
+12.0 dBm
+12.0 dBm
+3.0 dBm
+12.0 dBm
+12.0 dBm
+12.0 dBm
+18.0 dBm
+12.0 dBm
+12.0 dBm
-3.0 dBm
-7.0 dBm
-∞
-7.0 dBm
-7.0 dBm
-7.0 dBm
-7.0 dBm
-7.0 dBm
-7.0 dBm
+12.0 dBm
+12.0 dBm
+3.0 dBm
+12.0 dBm
+12.0 dBm
-∞ (*)
+12.0 dBm
+12.0 dBm
+12.0 dBm
+12.0 dBm
+9.0 dBm
+25.0 dBm
+12.0 dBm
+12.0 dBm
+12.0 dBm
+12.0 dBm
+12.0 dBm
+11.0 dBm
