39
RX-V861/HTR-6080/DSP-AX861SE/DSP-AX861
RX-V861/HTR-6080/DSP-AX861SE/
DSP-AX861
5. XCH-INPUT
入力ソースMULTICHANNELINPUTが選択されま
す。
サブメニューにより、6ch/8ch入力および6オーム/8
オームが選択可能です。
6chINPUT6-ohm
5. XCH-INPUT
The input source “MULTI CHANNEL INPUT” is se-
lected.
It is possible to select the 6 ch/8 ch and 6-ohm/8-ohm
by using the sub-menu.
6 ch INPUT 6-ohm
5.6CH INPUT_6 Ω
5.8CH INPUT_6 Ω
5.6CH INPUT_8 Ω
5.8CH INPUT_8 Ω
Input level Volume
SPEAKER OUT SUBWOOFER
OUTPUT
INPUT: MULTI CH INPUT
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
Both ch, -20 dBm +6.0 dB
FRONT L/R
+12.0 dBm
CENTER
+12.0 dBm
SURROUND L/R
+12.0 dBm -18.0 dBm
SURROUND BACK L/R
-∞
8chINPUT6-ohm8 ch INPUT 6-ohm
6chINPUT8-ohm6 ch INPUT 8-ohm
8chINPUT8-ohm8 ch INPUT 8-ohm
Input level Volume
SPEAKER OUT SUBWOOFER
OUTPUT
INPUT: MULTI CH INPUT
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
Both ch, -20 dBm +6.0 dB
FRONT L/R
+12.0 dBm
CENTER
+12.0 dBm
SURROUND L/R
+12.0 dBm -18.0 dBm
SURROUND BACK L/R
+12.0 dBm
Input level Volume
SPEAKER OUT SUBWOOFER
OUTPUT
INPUT: MULTI CH INPUT
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
Both ch, -20 dBm +6.0 dB
FRONT L/R
+12.0 dBm
CENTER
+12.0 dBm
SURROUND L/R
+12.0 dBm -18.0 dBm
SURROUND BACK L/R
-∞
Input level Volume
SPEAKER OUT SUBWOOFER
OUTPUT
INPUT: MULTI CH INPUT
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
Both ch, -20 dBm +6.0 dB
FRONT L/R
+12.0 dBm
CENTER
+12.0 dBm
SURROUND L/R
+12.0 dBm -18.0 dBm
SURROUND BACK L/R
+12.0 dBm
