4-6
6X4 MULTI-FUNCTION TILLER HANDLE
70
KIT P/N:6X4-42102-51
50
KIT P/N:6X4-42102-61
Part name Part No. Q’ty Remarks
Throttle cable 6H3-26301-01 1 530 mm (21 in.)
Shift cable 6H3-48321-11 1 610 mm (24 in.)
Cable clamp 63D-48538-00 2
Grommet 2 6H3-42725-30 1
Ext. bracket
6X4-42121-00-4D
1 45 mm (short)
10-pin main harness 6X4-82586-30 1 600 mm (24 in.)
Stud bolt 90116-10031 2 M10-70 mm
Lock nut 90185-10051 2 M10
Clamp 90464-09M42 1
Clamp 90465-13M36 2
Clip 90468-10005 2
Steering friction assy 692-42508-01 1 Shaft type
Part name Part No. Q’ty Remarks
Stay 63D-24364-10 1
Fuel pipe clamp 2 63D-24367-00 1
Throttle cable 63D-26301-01 1 530 mm (21 in.)
Shift cable 63D-48321-11 1 610 mm (24 in.)
Clamp 63D-48538-00 2
Clamp 63D-82361-00 1
10-pin main harness 6X4-82586-00 1 700 mm (26 in.)
Screw 90161-06M00 1 M6-25 mm
Lock nut 90185-10051 2 M10
Collar 90387-06M26 1
Clamp 90464-09M42 1
Clamp 90465-13M36 2
Clip 90468-10005 2
Bolt 97595-06416 2
Bolt 97595-06516 1
Bolt 97595-06535 1
Steering friction assy 63D-42508-00 1
To Next Page
