Yamaha F20BMH User Manual

8-9
CONVENTIONAL RIGGING KIT CONTENTS
TWIN-MOTOR KIT
L150-L300, LF115-LF250
P/N: 6YR-W0035-G3
Part name Part No. Q’ty Remarks
Wire-lead 6Y5-83553-20 1 2.5 m, 8 ft w/10 amps fuse
Tachometer assy 6Y5-8350T-90 1 Included instruction tag
EXT wire-lead 6Y5-83653-40 1 9 m, 31 ft
Twin-binnacle RCL box 704-48207-P1 1 Premium
Main wire-harness, 10-pin 6K1-8258A-40 1 8 m, 26 ft
Main wire-harness, 10-pin 61B-8258A-01 1 9.5 m, 32 ft
Clamp 90465-13M18 10
Twin-switch panel 6K1-82570-08 1 With DES control unit
Screw 90149-05M05 4 25 mm
Nut 95380-05600 4
Plane washer 92990-05600 4
Spring washer 92990-05100 4
Fuel mgt gauge 6Y5-8350F-00 1 Included instruction tag
Wire-lead 6Y5-83553-F1 1 8 m, 26 ft
Fuel flow sensor 6Y5-85752-02 2
Screw 90158-06003 4 68 mm
Instruction 61B-28107-A4 1

Yamaha F20BMH Specifications

General

Brand	Yamaha
Model	F20BMH
Category	Outboard Motor
Language	English
