5-26
HOUR METER
The hour meter provides the operator with useful at-a-glance information.
It monitors the number of hours a motor has been used since original installation.
* The transaction of time count when the engine is stopped differs on each hour-meter and YDIS, therefore
the elapsed time is not always equal on their equipments.
HOUR METER APPLICATIONS
HOUR METER DIMENSIONS
Ref. No. Description Part No. Applicable model
1 Mechanical 6Y5-83504-01
All electrical start models
2
Digital, Black panel 6Y7-83504-00
Digital, White panel 6Y7-83504-10
21
7.5 (0.3)
34.5 (1.36)
31.5 (1.24)
52 (2.05)
62 (2.44)
60 (2.36)
11 (0.43)
71.5 (2.81)
33 (1.3)
52 (2.05)
Mechanical Digital
mm (in.)mm (in.)
