5-5
E
POWR
ENGINE UNIT
5. Measure:
• Compression pressure
Out of specification
→
Refer to steps (b)
and (c).
6. Install:
• Spark plug
Minimum compression pressure
(reference data):
1,150 kPa
(11.5 kgf/cm
2
, 164 psi)
Measurement steps:
a. With the throttle wide open, crank the
engine until the reading on the compres-
sion gauge stabilizes.
NOTE:
The difference in compression pressure
between cylinders should not exceed 100
kPa (1 kgf/cm
2
, 14 psi).
b. If the compression pressure is extremely
high, check the cylinder head, valve sur-
faces and piston crown for carbon depos-
its.
Carbon deposits
→
Eliminate.
c. If the compression pressure is below the
minimum specification, squirt a few drops
of oil into the cylinder and measure
again.
Refer to the following table.
Compression pressure
(with oil applied into the cylinder)
Reading Diagnosis
Higher than
without oil
Piston ring wear,
piston wear or
damage
→
Repair.
Same as without
oil
Valves, cylinder
head gasket or pis-
ton possibly defec-
tive
→
Repair.
T
R
.
.
Spark plug:
13 N • m (1.3 kgf • m, 9.4 ft • lb)
To Next Page
