8-6
E
HULL
HOOD
HANDLEBAR
SERVICE POINTS
Handlebar inspection
1. Inspect:
• Handlebar
Bends/cracks/damage
→
Replace.
Handlebar switch inspection
Refer to “STARTING SYSTEM” in
Chapter 7.
Handlebar assembly installation
1. Install:
• Handlebar switch lead
1
NOTE:
Be sure to leave some slack in the handlebar
switch lead
1
in the area
a
shown in the illus-
tration.
2. Install:
• Upper handlebar holder
1
NOTE:
The upper handlebar holder should be installed
with the punch mark
a
facing forward.
CAUTION:
Clearance
b
should be narrower than
clearance
c
.
T
R
.
.
Handlebar holder bolt:
20 N • m (2.0 kgf • m, 14 ft • lb)
LOCTITE 572
Reference clearance:
b
: 1.5 mm (0.06 in)
c
: 3.5 mm (0.14 in)
