TIGHTENING TORQUES
Shift cable locknut
(Deluxe model only)
Nut — 1 3.8 0.38 2.7
572
LT
8-23
Steering cable locknut
(steering column side)
Nut — 1 6.5 0.65 4.7 8-23
Steering cable locknut
(jet pump side)
Nut — 1 6.8 0.68 4.9
572
LT
8-23
Steering cable seal Nut — 1 5.9 0.59 4.3 8-23
Steering cable bracket Bolt M6 1 6.9 0.69 5.0
572
LT
8-23
Speed sensor lead grommet Nut — 1 5.9 0.59 4.3 8-23
Hinge assembly Bolt M6 2 6.9 0.69 5.0 8-8
Hood lock assembly Bolt M5 2 1.9 0.19 1.4
572
LT
8-8
Hinge assembly Bolt M6 4 6.9 0.69 5.0
242
LT
8-8
Lid lock hook Bolt M6 2 6.9 0.69 5.0
242
LT
8-8
Mirror (Deluxe model only) Nut — 4 15 1.5 11 8-8
Shift handle lever
(Deluxe model only)
Screw M5 2 3.70.372.7
572
LT
8-11
Multifunction meter Bolt M5 4 3.9 0.39 2.8
572
LT
8-11
Engine hatch cover
(Deluxe model only)
Bolt M6 1 6.9 0.69 5.0
572
LT
8-11
Engine hatch cover Bolt M6 8 6.9 0.69 5.0
572
LT
8-11
Detent plate Bolt M6 2 8.0 0.8 5.8
572
LT
8-16
Shift lever bracket
(Deluxe model only)
Nut — 2 15 1.5 11 8-16
Pilot water outlet Nut — 1 4.2 0.42 3.0 8-17
Hand grip Nut — 4 6.9 0.69 5.0 8-28
Seat bracket Nut — 2 15 1.5 11 8-28
Seat lock projection Bolt — 1 26 2.6 19 8-28
Seat lock assembly Bolt M6 2 6.4 0.64 4.6
271
LT
8-28
Plate/rubber hose/exhaust
valve
Nut — 6 5.4 0.54 3.9 8-31
Hose clamp 1 ——2 3.7 0.37 2.7 8-31
Hose clamp 2 ——1 3.7 0.37 2.7 8-31
Joint clamp 1 and 4 ——2 3.7 0.37 2.7 8-31
Joint clamp 2 and 3
1st
——2
2.40.241.7
8-31
2nd 2.4 0.24 1.7
Sponson Bolt M810161.612
572
LT
8-36
Cleat Nut —
2
15 1.5 11 8-36
4
Spout Nut — 1 5.4 0.54 3.9 8-36
Protector (bow) Nut — 5 6.9 0.69 5.0 8-36
Bow eye Bolt M6 2 13 1.3 9.4 8-36
Drain plug/packing Screw M5 4 2.0 0.2 1.4 8-36
Engine mount Bolt M8 8 17 1.7 12
572
LT
8-38
Engine damper Bolt M6 2 6.6 0.66 4.8
271
LT
8-38
Part to tightened
Part
name
Thread
size
Q’ty
Tightening torque
Remarks
Refer to
page
N•mkgf•mft•lb
To Next Page
