Yamaha WR250X - Tail;Brake Light and Turn Signal Bulb Replacement

PERIODIC MAINTENANCE AND ADJUSTMENT
6-37
2
3
4
5
6
7
8
9
EAU24182
Tail/brake light
This model is equipped with an
LED-type tail/brake light.
If the tail/brake light does not come on,
have a Yamaha dealer check it.
EAU24205
Replacing a turn signal light
bulb
1. Remove the turn signal light lens
by removing the screw.
2. Remove the burnt-out bulb by
pushing it in and turning it counter-
clockwise.
3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the
screw. NOTICE: Do not over-
tighten the screw, otherwise the
lens may break.
[ECA11192]
1. Screw
2. Turn signal light lens
1
2
1. Turn signal light bulb
1
