INSPECTION STEPS
Use the following steps for checking the possibility of the malfunctioning engine being attributable to ignition system failure
and for checking the spark plug which will not spark.
*marked: Only when the ignition checker is used.
• Remove the following parts before inspection.
1. Seat
2. Fuel tank
• Use the following special tools in this inspection.
Spark gap test Spark → *Clean or replace spark plug.
No spark ↓
Check entire ignition system for connection.
(couplers, leads and ignition coil)
No good →
Repair or replace.
OK ↓
Check engine stop switch. No good → Replace.
OK ↓
Check ignition coil. (primary coil and secondary
coil)
No good →
Replace.
OK ↓
Check CDI magneto. (pickup coil and charging
coil)
No good →
Replace.
OK ↓
Check neutral switch. No good → Repair or replace.
OK ↓
Replace CDI unit.
Dynamic spark tester:
YM-34487
Ignition checker:
90890-06754
Pocket tester:
YU-3112-C/90890-03112
