Yamato DNF 400 User Manual

69
Replacement Parts Table
Common parts
Symbol Part Name Code No. Specification Manufacturer
X1/X2 Relay 2-05-000-0013 AHN36006 Matsushita
OH
Independent overheating
prevention device
2-10-011-0002 PAS3K1-0YB0Y Yamato Scientific
CT Current transformer 2-17-001-0002 CTL-6-S-400 URD
TH1/TH2
Temperature sensor
(K thermocouple)
1-16-003-0054 LCK-M1-2000-M Yamato Scientific
CONT PLANAR board 1-24-000-0108 IV CR2 FCJ
PIO Display circuit board LT00027240 PIO12 Yamato Scientific
FM1/FM2 Motor 2-14-000-0047 DC24V 10W CCW Yamato Scientific
DS1/DS2 Door switch 2-05-000-0054 LAB1L OMRON
DC1/DC2
RA1/RA2
Fan controller 2-14-000-0045 DC10V-24V Yamato Scientific
DNF400
Symbol Part Name Code No. Specification Manufacturer
ELB Earth leakage breaker 2-06-005-0001 BJS1532N Matsushita
H Heater DNF40-30020 100V 1.25kW Yamato Scientific
TF Transformer 2-18-000-0040
ⅣCR2 100V
Yamato Scientific
TM Terminal block 2-07-023-0001 MO11-0FX 4P TOYO
SSR SSR LT00028423 SSR-01 Yamato Scientific
Power cord LT00008924 T2-3c Yamato Scientific
DNF410
Symbol Part Name Code No. Specification Manufacturer
ELB Earth leakage breaker LT00028200 BJS1032S1Z Matsushita
H Heater DNF40-30270 200V 1.25kW Yamato Scientific
TF Transformer 2-18-000-0042
ⅣCR2 200V
Yamato Scientific
TM Terminal block 2-07-023-0001 MO11-0FX 4P TOYO
SSR SSR LT00028423 SSR-01 Yamato Scientific
Power cord 2-13-001-0008 T2-3b-0 Yamato Scientific
