York MILLENNIUM Y24 User Manual

102777-YIM-E-0206
Unitary Products Group 105
TABLE 51: SIMPLICITY CONTROL OUTPUTS
Name Range Resolution Precision Description
LED On - Off - - Status LED
Display
7 segment W/
Decimal Point
6 "Seven Segment LED /W decimal point"
H1
Class 1 Relay
Contacts
- - Heat 1 contactor output (Relay Contacts - 24 VAC/120 VAC)
H2
Class 1 Relay
Contacts
- - Heat 2 contactor output (Relay Contacts - 24 VAC/120 VAC)
H3
Class 1 Relay
Contacts
- - Heat 3 contactor output (Relay Contacts - 24 VAC/120 VAC)
C1
Class 1 Relay
Contacts
--
Compressor number one contactor output (Relay Contacts - 24
VAC/120 VAC)
C2
Class 1 Relay
Contacts
--
Compressor number two contactor output (Relay Contacts - 24
VAC/120 VAC)
C3
Class 1 Relay
Contacts
--
Compressor number three contactor output (Relay Contacts - 24
VAC/120 VAC)
C4
Class 1 Relay
Contacts
--
Compressor number four contactor output (Relay Contacts - 24
VAC/120 VAC)
CF1
Class 1 Relay
Contacts
--
Condenser Fan contactor output (Relay Contacts - 24 VAC/120
VAC)
CF2
Class 1 Relay
Contacts
--
Condenser Fan contactor output (Relay Contacts - 24 VAC/120
VAC)
Fan
Class 1 Relay
Contacts
- - Fan contactor output (Relay Contacts - 24 VAC/120 VAC)
Exhaust Fan (EXH)
Class 1 Relay
Contacts
--
Exhaust Fan contactor output (Relay Contacts - 24 VAC/120
VAC)
Supply Fan VFD 2 - 10 VDC - - This is a 2 - 10 volt output capable of 10 ma
Exhaust Fan
Damper (EXD)
2 - 10 VDC .1 VDC .1 VDC This is a 2 - 10 volt output capable of 10 ma
Hot Water Valve
(HWV)
2 - 10 VDC .1 VDC .1 VDC This is a 2 - 10 volt output capable of 10 ma
Hot Gas Reheat 2 - 10 VDC .1 VDC .1 VDC This is a 2 - 10 volt output capable of 10 ma
Economizer (ECO) 2 - 10 VDC .1 VDC .1 VDC This is a 2 - 10 volt output capable of 10 ma
X 24VDC - - This is a 24VDC output for Alarms
