York MILLENNIUM Y24 User Manual

102777-YIM-E-0206
58 Unitary Products Group
TABLE 30: SUPPLY FAN MOTOR AND DRIVE DATA
Model
Blower
RPM
Range
Motor Motor Pulley Blower Pulley Belts
HP
Frame
Size
Motor
Efficiency
(Std. Motor)
Motor
Efficiency
(Ultra Hi
Eff Opt)
Pitch Dia
(Inches)
Bore
(Inches)
Pitch Dia
(Inches)
Bore
(Inches)
Designation Qty
25 Ton
567 7.5 213T 88.5 91.7 4.5 1-3/8 13.9 2-3/16 BX56 2
692 10 215T 89.5 91 5.5 1-3/8 13.9 2-3/16 BX56 2
793 15 254T 91 91.7 6.3 1-5/8 13.9 2-3/16 BX56 2
894 20 256T 91 93 7.1 1-5/8 13.9 2-3/16 BX56 2
30 Ton
617 10 215T 89.5 91 4.9 1-3/8 13.9 2-3/16 BX56 2
743 15 254T 91 91.7 5.9 1-5/8 13.9 2-3/16 BX56 2
844 20 256T 91 93 6.7 1-5/8 13.7 2-3/16 5VX610 2
919 25 284T 91.7 93.6 7.1 1-7/8 13.7 2-3/16 5VX610 2
40 Ton
567 10 215T 89.5 91 4.5 1-3/8 13.9 2-7/16 BX67 2
642 15 254T 91 91.7 5.1 1-5/8 13.7 2-7/16 5VX710 2
717 20 256T 91 93 5.7 1-5/8 13.7 2-7/16 5VX710 2
768 25 284T 91.7 93.6 6.1 1-7/8 13.7 2-7/16 5VX710 2
TABLE 31: EXHAUST FAN DRIVE DATA
Model
Blower
RPM
Range
Motor Motor Pulley Blower Pulley Belts
HP
Frame
Size
Motor Eff
(Std.
Motor)
Motor
Eff (Hi
Eff opt)
Pitch Dia
(Inches)
Bore
(Inches)
Pitch Dia
(Inches)
Bore
(Inches)
Designation Qty
25
Ton
732 5 213T 87.5 89.5 4.9 1-3/8 11.3 2-3/16 BX63 2
827 7.5 215T 88.5 91.7 5.5 1-3/8 11.3 2-3/16 BX63 2
955 10 215T 89.5 91 6.3 1-5/8 11.3 2-3/16 BX63 2
30
Ton
852 7.5 213T 84 86.5 5.5 1-3/8 11.3 1-11/16 B65 2
976 10 215T 86.5 89.5 6.3 1-3/8 11.3 1-11/16 B65 2
1069 15 254T 85.7 89.5 6.9 1-3/8 11.3 1-11/16 B65 2
40
Ton
852 7.5 184T 84 86.5 5.5 1-3/8 11.3 1-11/16 B65 2
976 10 215T 86.5 89.5 6.3 1-3/8 11.3 1-11/16 B65 2
1069 15 254T 85.7 89.5 6.5 1-3/8 11.3 1-11/16 B65 2
