TABLE 12: REFRIGERANT CHARGE
UNIT (TONS) MODEL TYPE
FACTORY/ FIELD
CHARGED
CHARGE
SYS #1 SYS #2 SYS #3 SYS #4
25 wo/HGBP R22 Factory 27 lb. / 0 oz. 26lb / 0oz - -
25 w/HGBP R22 Factory 27 lb. / 8 oz. 26 lb. / 0oz - -
30 wo/HGBP R22 Factory 13 lb. / 4 oz. 13 lb. / 8 oz. 13 lb. / 8 oz. -
30 w/HGBP R22 Factory 14 lb. / 0 oz. 13 lb. / 8 oz. 13 lb. / 8 oz. -
30 wo/HGBP
1
R22 Factory 14 lb. / 6 oz. 14 lb. / 10 oz. 14 lb. / 10 oz. -
30 w/HGBP
1
R22 Factory 15 lb. / 2 oz. 14 lb. / 10 oz. 14 lb. / 10 oz. -
40 wo/HGBP R22 Factory 15 lb. / 5 oz. 15 lb. / 4 oz. 15 lb. / 5 oz. 15 lb. / 15 oz.
40 w/HGBP R22 Factory 15 lb. / 13 oz. 15 lb. / 4 oz. 15 lb. / 5 oz. 15 lb. / 15 oz.
1.
With high capacity evaporator coil.
TABLE 13: ELECTRICAL DATA BASIC UNIT - 25 TON
VOLTAGE
COMPRESSORS COND. FAN MOTOR SUPPLY AIR MOTOR BASIC UNIT
QTY. RLA LRA QTY FLA HP FLA MCA
MAX OVERCURRENT
PROTECTION DEVICE
208-3-60 2 45.7 350 4 7.6 ea.
7.5 24.2 157 200
10 30.8 164 200
15 46.2 180 225
20 59.4 196 250
230-3-60 2 45.7 350 4 6.9 ea.
7.5 22.0 152 175
10 28.0 158 200
15 42.0 172 200
20 54.0 187 225
460-3-60 2 24.3 158 4 3.5 ea.
7.5 11.0 80 100
10 14.0 83 100
15 21.0 90 110
20 27.0 96 110
575-3-60 2 19.3 125 4 3.0 ea.
7.5 9.0 64 80
10 11.0 66 80
15 17.0 72 90
20 22.0 78 100
