York MILLENNIUM Y24 User Manual

102777-YIM-E-0206
Unitary Products Group 59
TABLE 32: POWER EXHAUST - ONE FORWARD CURVED FAN 25 TON
1
AIRFLOW CFM
AVAILABLE EXTERNAL STATIC PRESSURE (IWG)
0.2 0.4 0.6 0.8 1.0
RPM
BHP
2
RPM
BHP
2
RPM
BHP
2
RPM
BHP
2
RPM
BHP
2
2000 --- --- --- --- 524 0.32 609 0.42 685 0.54
3000 --- --- 450 0.41 531 0.51 605 0.64 672 0.77
4000 442 0.63 496 0.74 562 0.87 626 1.00 687 1.16
5000 524 1.15 566 1.29 609 1.43 663 1.58 717 1.74
6000 612 1.84 646 2.08 679 2.25 717 2.43 762 2.60
7000 703 2.86 731 3.16 759 3.37 787 3.57 820 3.78
8000 791 3.63 821 4.09 844 4.54 868 4.99 892 5.23
9000 877 5.53 911 5.88 932 6.22 953 6.57 974 6.92
10000 967 8.02 1004 8.34 1022 8.66 1041 8.98 1059 9.30
AIRFLOW CFM
AVAILABLE EXTERNAL STATIC PRESSURE (IWG)
1.2 1.4 1.6 1.8 2.0
RPM
BHP
2
RPM
BHP
2
RPM
BHP
2
RPM
BHP
2
RPM
BHP
2
2000 754 0.66 819 0.78 878 0.90 933 1.03 986 1.16
3000 736 0.92 797 1.08 854 1.24 909 1.41 961 1.58
4000 743 1.32 799 1.47 850 1.66 900 1.84 948 2.04
5000 768 1.90 818 2.08 865 2.28 911 2.48 955 2.68
6000 806 2.78 850 2.95 895 3.17 937 3.40 978 3.62
7000 857 3.98 895 4.19 933 4.39 972 4.60 1010 4.80
8000 921 5.47 953 5.71 985 5.95 1018 6.19 1052 6.43
9000 995 7.27 1020 7.59 1048 7.86 1075 8.13 1103 8.39
10000 1077 9.62 1096 9.94 - - - - - -
1.
Fan performance is based on system/cabinet effects and backdraft damper effects at standard air density and 0° elevation.
2.
BHP does not include drive losses. Multiply BHP by 1.05 to account for drive losses.
