JOHNSON CONTROLS
46
Form 150.63-NM9
Issue date: 5/20/2021
SECTION 5 – TECHNICAL DATA
Electrical data
YCUL0020 - YCUL0072
See Electrical Notes on page 45.
CHILLER
MODEL
YCUL
VOLT HZ
MINIMUM
CIRCUIT
AMPS
MCA
MIN N/F
DISC SW
MDSW
MIN
DUAL
ELEM
FUSE
MAX
DUAL
ELEM
FUSE
MAX CB
SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 FAN COMPR 1 COMPR 2 FAN
RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA QTY FLA LRA
0020
200 60 101 150 125 125 42.2 250 42.2 250 2 7.6 30.9
230 60 94 100 110 125 39 250 39 250 2 7.4 37
380 60 54 60 60 70 22.5 155 22.5 155 2 4.5 22.3
400 50 45 60 50 60 18.6 114 18.6 114 2 4 19
460 60 45 60 50 60 18.6 114 18.6 114 2 3.4 17.2
575 60 36 60 40 50 14.9 100 14.9 100 2 2.9 14.6
0024
200 60 108 150 125 150 45.4 250 45.4 250 2 7.6 30.9
230 60 100 150 125 125 42 250 42 250 2 7.4 37
380 60 58 60 70 80 24.2 155 24.2 155 2 4.5 22.3
400 50 48 60 60 60 20 125 20 125 2 4 19
460 60 48 60 60 60 20 125 20 125 2 3.4 17.2
575 60 39 60 45 50 16 100 16 100 2 2.9 14.6
0031
200 60 136 150 175 175 55.8 425 51.3 300 2 7.6 30.9
230 60 136 150 150 175 55.8 425 51.3 300 2 7.4 37
380 60 81 100 90 110 36 239 26.9 189 2 4.5 22.3
400 50 65 100 80 90 26.9 198 23.1 150 2 4 19
460 60 64 100 80 90 26.9 198 23.1 150 2 3.4 17.2
575 60 55 60 70 70 23.7 148 19.9 109 2 2.9 14.6
0035
200 60 151 200 175 200 59.9 425 59.9 425 2 7.6 30.9
230 60 140 150 175 175 55.5 425 55.5 425 2 7.4 37
380 60 81 100 90 110 32 239 32 239 2 4.5 22.3
400 50 68 100 80 90 26.4 198 26.4 198 2 4 19
460 60 67 100 80 90 26.4 187 26.4 187 2 3.4 17.2
575 60 54 60 60 70 21.1 148 21.1 148 2 2.9 14.6
0045
200 60 224 250 250 250 45.4 250 45.4 250 2 7.6 44 45.4 250 45.4 250 2 7.6 44
230 60 209 250 225 250 42 250 42 250 2 7.4 37 42 250 42 250 2 7.4 37
380 60 121 150 150 150 24.2 155 24.2 155 2 4.5 22.3 24.2 155 24.2 155 2 4.5 22.3
400 50 102 150 110 110 20 125 20 125 2 4 19 20 125 20 125 2 4 19
460 60 99 150 110 110 20 125 20 125 2 3.4 17.2 20 125 20 125 2 3.4 17.2
575 60 80 100 90 90 16 100 16 100 2 2.9 14.6 16 100 16 100 2 2.9 14.6
0051
200 60 228 250 250 250 47 250 47 250 2 7.6 44 45.4 250 45.4 250 2 7.6 44
230 60 212 250 225 250 43.5 250 43.5 250 2 7.4 37 42 250 42 250 2 7.4 37
380 60 123 150 150 150 25.1 155 25.1 155 2 4.5 22.3 24.2 155 24.2 155 2 4.5 22.3
400 50 103 150 110 110 20.7 125 20.7 125 2 4 19 20 125 20 125 2 4 19
460 60 101 150 110 110 20.7 125 20.7 125 2 3.4 17.2 20 125 20 125 2 3.4 17.2
575 60 81 100 90 90 16.6 100 16.6 100 2 2.9 14.6 16 100 16 100 2 2.9 14.6
0055
200 60 248 400 300 300 51.3 300 51.3 300 2 7.6 44 51.3 300 51.3 300 2 7.6 44
230 60 248 400 300 300 51.3 300 51.3 300 2 7.4 19.1 51.3 300 51.3 300 2 7.4 19.1
380 60 132 150 150 150 26.9 139 26.9 139 2 4.5 23.1 26.9 139 26.9 139 2 4.5 23.1
400 50 106 150 125 125 21.8 140 21.8 140 2 3.4 17.5 21.8 140 21.8 140 2 3.4 17.5
460 60 114 150 125 125 23.1 150 23.1 150 2 4 19 23.1 150 23.1 150 2 4 19
575 60 96 150 110 110 19.9 109 19.9 109 2 2.9 15.3 19.9 109 19.9 109 2 2.9 15.3
