Figure 1: ZF180-240 Component Location
Table 1: ZF180-240 Unit Limitations
Size (Tons) Unit Voltage
Unit Limitations
Applied Voltage Outdoor DB Temp
Min Max Max (°F) / (°C)
180 (15) 380/415-3-50 342 457 125.6 / 52
240 (20) 380/415-3-50 342 457 125.6 / 52
ELECTRIC HEATER LOCATION
(OPTIONAL ELECTRIC/ELECTRIC UNITS)
HIGH
EFFICIENCY
COMPRESSORS
COPPER TUBE/ALUMINUM FIN
CONDENSER COILS
ELECTRICAL
DISCONNECT
MOUNTING
LOCATION
(Field installed)
KNOCKOUT FOR
SIDE CONTROL
WIRING ENTRY
KNOCKOUT
FOR SIDE
POWER WIRING
ENTRY SIDE
KNOCKOUTS FOR SIDE
GAS SUPPLY ENTRY
HOLE FOR BOTTOM
GAS SUPPLY ENTRY
POWER VENTOR MOTOR
WITH POST PURGE CYCLE
BELT-DRIVE
BLOWER MOTOR
FULL PERIMETER
14 GAUGE BASE RAILS
WITH LIFTING HOLES
1" NPTI
CONDENSATE DRAIN
2" DISPOSABLE
FILTERS
LONG LASTING
POWDER PAINT FINISH
20 GAUGE
ALUMINIZED STEEL
TUBULAR HEAT EXCHANGERS
GAS/ELECTRIC
UNIT SHOWN
