RETURN AIR
SUPPLY AIR
OUTDOOR AIR
(Discharge)
OUTDOOR AIR
(Economizer)
3181 (125-1/4") (180)
3461 (136-1/4") (240)
1235 (48-5/8") (180)
1337 (52-5/8") (240)
616 (24-1/4") (180)
895 (35-1/4") (240)
1235 (48-5/8") (180)
1337 (52-5/8") (240)
3181 (125-1/4") (180)
3461 (136-1/4") (240)
616 (24-1/4") (180)
895 (35-1/4") (240)
RETURN AIR
OUTDOOR AIR
(Economizer)
SUPPLY AIR
OUTDOOR AIR
(Discharge)
1061903-XIM-A-0713
Johnson Controls Unitary Products 9
Figure 6: Unit Dimensions - ZF Gas Heat
Figure 5: Unit Dimensions - ZF Cool & Electric Heat
