User Manual 3PH HYD5000-HYD20000-ZSS
Rev. 1.1 16/03/2021
Identification: MD-AL-GI-00
Rev. 1. of 16/03/2021 - Application: GID
3.5. Wall installation position
The inverter must be placed in a dry and clean place for proper functioning. The area must be tidy and
convenient for installation, and well-ventilated to prevent overheating. DO NOT place it near
flammable or explosive materials.
The AC overvoltage of the 3PH HYD5000-HYD20000-ZSS inverter belongs to Category III.
Maximum operating altitude: 2000 m.
Ambient temperature range: -25°C ~ 60°C.
Relative humidity: 0 ~ 100% (non-condensing).
Figure 6 - Correct positioning of the inverter (1)
Figure 7 - Correct positioning of the inverter (2)
