5. Connect the terminal to the machine port and turn the clamp in a clockwise direction.
Figure 52 - Terminal clamping
4.5. Grid connection
The inverter is equipped with an integrated unit for monitoring the residual current; when the
inverter detects that the residual current exceeds 300mA, the connection to the grid will be quickly
disconnected.
Procedure:
1. Select the type of cable and the appropriate specifications according to
2. Table 6.
3. Pass the wire through the terminal.
Figure 53 - Passing of the wire through the terminal
