Data Capture
137
Pairing the RS507/RS507X/RS6000 Hands-Free Imager
To connect the RS507/RS507X or RS6000 imager to the device, use one of the following methods:
• Near Field Communication (NFC) (RS6000 only)
• Simple Serial Interface (SSI)
• Bluetooth Human Interface Device (HID) Mode.
Pairing Using Near Field Communication
The device provides the ability to pair the RS6000 using NFC.
NOTE: RS6000 Only.
To pair using NFC:
1. Ensure that the RS6000 is in SSI mode. Refer to the RS6000 User Guide for more information.
2. Ensure that NFC is enabled on the device.
3. Align the NFC icon on the RS6000 with the NFC antenna on the device.
The RS6000 Status LED blinks blue indicating that the RS6000 is attempting to establish connection with
the device. When connection is established, the Status LED turns off and the RS6000 emits a single string
of low/high beeps.
A notification appears on the Notification panel and the icon appears in the Status bar.
Figure 132 Align NFC Antennas
Pairing in HID Mode Using Near Field Communication
The device provides the ability to pair the RS6000 in HID mode using NFC.
NOTE: RS6000 Only.
To pair in HID mode using NFC:
1. Ensure that NFC is enabled on the device.
2. Ensure that Bluetooth is enabled on the device.
