Accessories
177
Installing the Trigger Handle Plate
1. Press and hold the Power button until the menu appears.
2. Touch Power off.
3. Touch OK.
4. Press in the two battery latches.
5. Lift the battery from the device.
6. Remove the hand strap filler plate from the hand strap slot. Store the hand strap filler plate in a safe place
for future replacement.
Figure 177 Remove Hand Strap Plate
7. Insert the attachment plate into the hand strap slot.
Figure 178 Insert Trigger Handle Plate
8. Insert the battery, bottom first, into the battery compartment in the back of the device.
9. Rotate the top of the battery into the battery compartment.
10.Press the battery down into the battery compartment until the battery release latches snap into place.
