Accessories
176
Trigger Handle
The Trigger Handle adds a gun-style handle with a scanning trigger to the device. It increases comfort when
using the device in scan-intensive applications for extended periods of time.
NOTE: The Attachment Plate with Tether can only be used with Charge Only cradles.
Figure 175 Trigger Handle
Installing the Attachment Plate to Trigger Handle
NOTE: Attachment Plate with Tether only.
To install the attachment plate to the Trigger Handle:
1. Insert the loop end of the tether into the slot on the bottom of the handle.
2. Feed the attachment plate through the loop.
Figure 176 Install Attachment Plate to Handle
3. Pull the attachment plate until the loop tightens on the tether.
Trigger
Attachment Plate with
Tether
Latch
Release Button
Attachment Plate
without Tether
