Zebra TC77 User Manual

226
Technical Specifications
Introduction
The following sections provide technical specification for the device.
Table 23 Device Technical Specifications
Item Description
Physical Characteristics
Dimensions Height: 161 mm (6.3 in.)
Width: 84 mm (3.3 in.)
Depth: 28 mm (1.1 in.)
Weight 376 g (13.3 oz)
Display 4.7 in. High Definition (1280 x 720); exceptionally bright image; optically
bonded to touch panel with Gorilla Glass ™ protection
Touch Panel Capacitive touch
Backlight Light Emitting Diode (LED) backlight
Battery Pack Rechargeable Lithium Ion 3.7V, 4,620 mAh battery
Expansion Slot User accessible microSD up to 32 GB SDHC and up to 256 GB SDXC
support
Connection Interface Universal Serial Bus (USB) 2.0 High Speed (host and client)
Notification Audible tone plus multi-color LEDs, vibration
Voice and Audio Three microphone support with noise cancellation; vibrate alert; speaker;
Bluetooth wireless headset support. High quality speaker phone with up to
108 db SPL volume; PTT headset support; Cellular circuit switch voice; HD
Voice
Performance Characteristics
CPU 2.2 GHz hex core 64 bit processor (Snapdragon 660)
Operating System Android 8.1 Oreo
Memory 4 GB RAM/32 GB Flash
Output Power USB - 5 VDC @ 500 mA max
User Environment
Operating Temperature -20°C to 50°C (-4°F to 122°F)

Zebra TC77 Specifications

General

Display diagonal	4.7 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash), SD, SDHC, SDXC
Number of cores	8
Processor family	Snapdragon
Processor frequency	2.2 GHz
Processor manufacturer	Qualcomm
Operating system version	8.1
Operating system installed	Android
Data network	2G, 3G, EDGE, GPRS, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, EAP-TTLS, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Certification	WFA (802.11n, WMM-PS, 801.11ac, PMF)
Product color	Black, Silver
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP65, IP68
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
