195
MAIN TECHNICAL PARAMETERS
TRACTOR EQUIPPED WITH SYNCHRONIZED TRANSMISSION - SPEED 30 KM.H
-1
Shifted
gear
Ground
PTO speed
Tractor travel speed (km.h
-1
) at rated engine speed and at below stated tire dimensions of
rear wheels
14,9 - 28 16,9 - 28 12,4 - 36 16,9 - 30 13,6 - 36 18,4 - 30 16,9 - 34 18,4 - 34
1 293,43 5,59 5,85 6,03 6,07 6,24 6,29 6,51 6,72
2 418,20 7,97 8,34 8,59 8,65 8,90 8,96 9,27 9,58
3 590,96 11,26 11,78 12,13 12,22 12,57 12,66 13,10 13,54
4 935,05 17,81 18,64 19,20 19,34 19,90 20,04 20,73 21,43
5 1344,44 25,61 26,81 27,61 27,81 28,61 28,81 29,81 30,81
1L 293,43 1,42 1,48 1,53 1,54 1,58 1,59 1,65 1,70
2L 418,20 2,02 2,11 2,18 2,19 2,25 2,27 2,35 2,43
3L 590,96 2,85 2,99 3,07 3,10 3,19 3,21 3,32 3,43
4L 935,05 4,51 4,72 4,87 4,90 5,04 5,08 5,25 5,43
5L 1344,44 6,49 6,79 7,00 7,05 7,25 7,30 7,55 7,81
R -364,92 6,95 7,28 7,49 7,55 7,76 7,82 8,09 8,36
RL -364,92 1,76 1,84 1,90 1,91 1,97 1,98 2,05 2,12
L - reduction, R – reverse gear
