Ziehm Imaging, Inc. Vision Installation Manual MAN 06-0015, Rev. A Page 35

Maintenance Report: Smallest Field Size

Fig. 24 Measuring the Smallest Field Size

7. Enter the Integrated Service Functions mode, select Program 1, and restore the

value to the one recorded earlier. Save these settings and exit the Integrated Ser-

vice Functions mode.

Smallest field size: Film (A) ________ cm (B) __________ cm

a. Reject if smallest field size is greater than 5 cm x 5 cm.
