ZXA10C300CongurationManual(CLI)
ZXAN(config)#add-shelfshelfno1shelftypeETSI_SHELF
Note:
TheZXA10C300supportsonlyoneshelfcurrently,andthusshelfnocanonlybe1.
3.(Optional)Querytheshelfconguration.
ZXAN(config)#showshelf
RackShelfShelfTypeCleiCodeSerial-Number
------------------------------------------------------------------------------
11ETSI_SHELFUNKNOWN10011001C3000090
000000000000
–EndofSteps–
Result
Aftertheshelfisadded,thesystemwillautomaticallyaddtwoswitchingandcontrolcards.
ZXAN(config)#showcard
RackShelfSlotCfgTypeRealTypePortHardVerSoftVerStatus
----------------------------------------------------------------------------
1110SCXNSCXN4120900V2.0.0INSERVICE
1111SCXNSCXN4120900V2.0.0STANDBY
1.3.3AddingaCard
Whenreplacingthecardtypeduringcommissioningorcapacityexpansion,youneedto
addacard.
Context
Table1-3describesthecardcongurationsfora19-inchshelf.
Table1-3CardCongurationsfora19-InchShelf
SlotNumberCardType
0/1Powercard
2–9PONinterfacecard,TDMinterfacecard,Ethernetinterfacecard,and
P2Pinterfacecard
10/11Switchingandcontrolcard
12–17PONinterfacecard,TDMinterfacecard,Ethernetinterfacecard,and
P2Pinterfacecard
18Commoninterfacecard
19/20Uplinkcard
1-10
SJ-20130520164529-007|2013-06-30(R1.0)ZTEProprietaryandCondential

Zte ZXA10 C300 Specifications

General

Model	ZXA10 C300
Manufacturer	ZTE
Humidity	5% to 95% (non-condensing)
Uplink Ports	2 x 10GE
Supported Standards	IEEE 802.3ah, ITU-T G.984.x
GPON Ports per card	8
EPON Ports per card	8
Ports	GPON/EPON ports
Storage Temperature	-40°C to +70°C
Dimensions	482.6 mm
