ZXA10C300CongurationManual(CLI)
ItemData
T-CONTbandwidthprole5Prolename:2M
Bandwidthtype:type1
Fixedbandwidth:2000kbps
Steps
1.InGPONcongurationmode,createaT-CONTbandwidthprole.
ZXAN(config)#gpon
ZXAN(config-gpon)#profiletcont20Mtype5fixed2000assured5000maximum20000
[Successful]
ZXAN(config-gpon)#profiletcont15Mtype4maximum15000
[Successful]
ZXAN(config-gpon)#profiletcont10Mtype3assured5000maximum10000
[Successful]
ZXAN(config-gpon)#profiletcont5Mtype2assured5000
[Successful]
ZXAN(config-gpon)#profiletcont2Mtype1fixed2000
[Successful]
2.(Optional)QuerytheT-CONTbandwidthproleconguration.
ZXAN(config-gpon)#showgponprofiletcont
Name:default
TypeFBW(kbps)ABW(kbps)MBW(kbps)
11000000
Name:20M
TypeFBW(kbps)ABW(kbps)MBW(kbps)
52000500020000
Name:15M
TypeFBW(kbps)ABW(kbps)MBW(kbps)
40015000
Name:10M
TypeFBW(kbps)ABW(kbps)MBW(kbps)
30500010000
Name:5M
TypeFBW(kbps)ABW(kbps)MBW(kbps)
2050000
Name:2M
TypeFBW(kbps)ABW(kbps)MBW(kbps)
1200000
–EndofSteps–
2-8
SJ-20130520164529-007|2013-06-30(R1.0)ZTEProprietaryandCondential

Zte ZXA10 C300 Specifications

General

Model	ZXA10 C300
Manufacturer	ZTE
Humidity	5% to 95% (non-condensing)
Uplink Ports	2 x 10GE
Supported Standards	IEEE 802.3ah, ITU-T G.984.x
GPON Ports per card	8
EPON Ports per card	8
Ports	GPON/EPON ports
Storage Temperature	-40°C to +70°C
Dimensions	482.6 mm
