Zte ZXR10 5900 Series User Manual

ZXR105900/5200SeriesUserManual(BasicCongurationVolume)
Parametermode<mode>:blindindicatesColor-Blindmodeand
awareindicatesColor-Awaremode.
Parameterdrop-yellow:indicatesdroppingyellowpackets;
packetswillbeforwardedbydefault.
Parameterforward-red:indicatesforwardingredpackets;pack-
etswillbeforwardedbydefault.
Parameterremarkindicatesremarkingserviceparameterofpack-
etswithcolor:
�remark-red-dp:Remarkdropprecedenceofredpackets,pri-
orityparameterincludeshigh,mediumandlow.
�remark-red-dscp:RemarkDSCPpriorityofredpackets,pri-
orityparameteris0~63.
�remark-yellow-dp:Remarkyellowpacketdptoparameter
ofhigh,mediumorlow.
�remark-yellow-dscp:Remarkyellowpacket’sdscpvalue
from0to63andonevaluecanbechosen..
ExampleThisexampleshowsthetrafcpolicyofpacketssenttothedesti-
nationIPaddressof168.2.5.5onportofgei_1/1andbandwidth
issetto10M.
ZXR10(config)#aclextendednumber100
ZXR10(config-ext-acl)#rule1permitipany
168.2.5.50.0.0.0
ZXR10(config-ext-acl)#exit
ZXR10(config)#traffic-limitinrule-id1cir
10000cbs2000pir10000pbs2000modeblind
ZXR10(config)#interfacegei_1/1
ZXR10(config-gei_1/1)#ipaccess-group100in
ConfiguringTrafficShaping
CommandFunction
ZXR10(config-gei_1/x)#traffic-shapedata-rate
<rate-value>burst-size<value>
Thiscongurestrafcshaping
fortheport.
ExampleThisexampleshowstheconductionoftrafcshapingonport
gei_1/1andcongurestheportrateas20M.
ZXR10(config)#interfacegei_1/1
ZXR10(config-gei_1/1)#traffic-shapedata-rate20000burst-size4
ConfiguringQueueBandwidthLimit
CommandFunction
ZXR10(config-gei_1/x)#traffic-shapequeue
<queue-no>{max-datarate-limit<max-daterate-vlaue
>|min-gua-datarate<min-datarate-vlaue>}
Thisconguresqueuemaximum
andminimumbandwidthlimit.
74CondentialandProprietaryInformationofZTECORPORATION
