Chapter 5
Evaluation Tool System Configuration
using the GUI
The evaluation tool GUI is PC-based software that allows you to configure the operating
modes of the ADCs and DACs. The GUI also generates test patterns which can be
downloaded for DAC testing and manages the upload of data from the ADCs for analysis in
the GUI. The GUI shipped with the Xilinx evaluation board supports most of the API
functions and configuration options for the ADC and DACs. The GUI also supports the
testing of all ADCs and DACs, both individually and simultaneously. Details of the supported
configuration are outlined in the following sections.
The GUI is further documented in the RF Data Converter Interface User Guide (UG1309)
[Ref 10].
