114 ACH580 E-Clipse bypass and packaged drive user manual
Embedded fieldbus
BACnet protocol technical data – system
System overview -
When bypass parameter 1625 COMM CTL = (0) DRIVE ONLY, the drive’s BACnet
objects are supported using the drive’s device address. The bypass’s BACnet
objects related to the control word are no longer valid See Communication setup –
EFB on page 79.
Bypass BACnet objects not valid
When bypass parameter 1625 COMM CTL = (1) SYSTEM, the drive’s BACnet
following objects related to control are no longer available when using the drive’s
device address.
Drive BACnet objects not valid
Drive overview
Bypass parameter Group 58 defines features used by all Embedded Fieldbus (EFB)
protocols.
Note: The system will function as a master with MAC IDs in the range of 1-127. With
MAC ID settings of 128-254, the drive is in slave only mode.
Changes made to drive parameter Group 58, EFB Protocol, do not take affect until
you perform one of the following:
• Cycle the bypass power OFF and ON, or
• Set bypass parameter 5803 to 0, and then back to a unique MAC ID, or
• Use the ReinitializeDevice service.
Point # Name
BV10 RUN/STOP CMD
BV11 OVERRIDE CMD
BV12 RUN PERMISSIVE CMD
BV14 FAULT RESET
BV15 START INTERLOCK 1
BV16 START INTERLOCK 2
BV17 START INTERLOCK 3
BV18 START INTERLOCK 4
Point # Name
BV10 RUN/STOP CMD
BV12 RUN PERMISSIVE CMD
BV20 START INTERLOCK 1
BV21 START INTERLOCK 2
