206 ACH580 E-Clipse bypass and packaged drive user manual
Technical data
460 Volt fuses for vertical enclosures
575 Volt fuses for vertical enclosures
Type Code
1
Nominal Output
Ratings
Base
Drive
Frame
Size
Internal Drive
Fuse Rating
External Fuse for
Disconnect Option
Drive
Current
Package
Power
Class
Max
Current
Rating
Class
Max
Current
Rating
AHP
460 Volts
ACH580-VxR-02A1-4 2.1 1 R1 Class CC 15A Class J 15A
ACH580-VxR-03A0-4 3.0 1.5 R1 Class CC 15A Class J 15A
ACH580-VxR-03A5-4 3.5 2 R1 Class CC 15A Class J 15A
ACH580-VxR-04A8-4 4.8 3 R1 Class CC 15A Class J 15A
ACH580-VxR-07A6-4 7.6 5 R1 Class CC 15A Class J 20A
ACH580-VxR-012A-4 12 7.5 R1 Class CC 15A Class J 25A
ACH580-VxR-014A-4 14 10 R2 Class CC 30A Class J 35A
ACH580-VxR-023A-4 23 15 R2 Class CC 30A Class J 45A
ACH580-VxR-027A-4 27 20 R3 Class T 40A Class J 60A
ACH580-VxR-034A-4 34 25 R3 Class T 60A Class J 60A
ACH580-VxR-044A-4 44 30 R3 Class T 60A Class J 60A
ACH580-VxR-052A-4 52 40 R4 Class T 80A Class J 100A
ACH580-VxR-065A-4 65 50 R4 Class T 90A Class J 100A
ACH580-VxR-077A-4 77 60 R4 Class T 100A Class J 100A
1) “VxR” represents both VCR and VDR.
Type Code
1
Nominal Output
Ratings
Base
Drive
Frame
Size
Internal Drive
Fuse Rating
External Fuse for
Disconnect Option
Drive
Current
Package
Power
Class
Max Current
Rating
Class
Max Current
Rating
AHP
575 Volts
2
ACH580-VxR-02A7-6 2.7 2 R2 Class CC 30A Class J 15A
ACH580-VxR-03A9-6 3.9 3 R2 Class CC 30A Class J 15A
ACH580-VxR-06A1-6 6.1 5 R2 Class CC 30A Class J 15A
ACH580-VxR-09A0-6 9 7.5 R2 Class CC 30A Class J 20A
ACH580-VxR-011A-6 11 10 R2 Class CC 30A Class J 25A
ACH580-VxR-017A-6 17 15 R2 Class CC 30A Class J 40A
ACH580-VxR-022A-6 22 20 R3 Class T 40A Class J 50A
ACH580-VxR-027A-6 27 25 R3 Class T 40A Class J 60A
1) “VxR” represents both VCR and VDR.
2) VCR is rated 600Y/347V. For use on a solidly grounded Wye source only.
