24 ACH580 E-Clipse bypass and packaged drive user manual
Installation
14. Press the OFF key on the drive control panel. Note that the bottom line of the drive
control panel display indicates “Off.”
If the ACH580 Drive and E-Clipse Bypass operate according to these steps, and you
have familiarized yourself with their operation, disconnect and lock out power to
prepare for the next test.
Refer to the Safety instructions section on page v for the warnings all personnel who
do work on the drive, motor cable or motor need to follow.
If the drive does not operate according to these steps, refer to the ACH580-01
Hardware Manual (3AXD50000044839).
