ACH580 E-Clipse bypass and packaged drive user manual 211
Technical data
Dimensional references
The following tables contain dimensional references that identify the dimensional
information applying to a given type code.
Vertical enclosures – E-Clipse bypass drive with circuit breaker
Type Code
Nominal Output Ratings
Frame
Size
Dim
Ref
Drive Current
A
Package
Power
HP
U
1
= 208 to 240V. Power ratings are valid at nominal output voltage U
N
= 208/230 V 60 Hz
ACH580-VxR-04A6-2 4.6 1 R1 Vx1-1
ACH580-VxR-06A6-2 6.6 1.5 R1 Vx1-1
ACH580-VxR-07A5-2 7.5 2 R1 Vx1-1
ACH580-VxR-10A6-2 10.6 3 R1 Vx1-1
ACH580-VxR-017A-2 16.7 5 R1 Vx1-1
ACH580-VxR-024A-2 24.2 7.5 R2 Vx1-2
ACH580-VxR-031A-2 30.8 10 R2 Vx1-3
ACH580-VxR-046A-2 46.2 15 R3 Vx1-3
ACH580-VxR-059A-2 59.4 20 R3 Vx1-4
ACH580-VxR-075A-2 74.8 25 R4 Vx1-4
1) “VxR” represents VCR and VDR.
Type Code
Nominal Output Ratings
Frame
Size
Dim
Ref
Drive Current
A
Package
Power
HP
U
1
= 440 to 480V. Power ratings are valid at nominal output voltage U
N
= 460 V 60 Hz
ACH580-VxR-02A1-4 2.1 1 R1 Vx1-1
ACH580-VxR-03A0-4 3 1.5 R1 Vx1-1
ACH580-VxR-03A5-4 3.5 2 R1 Vx1-1
ACH580-VxR-04A8-4 4.8 3 R1 Vx1-1
ACH580-VxR-07A6-4 7.6 5 R1 Vx1-1
ACH580-VxR-012A-4 12 7.5 R1 Vx1-1
ACH580-VxR-014A-4 14 10 R2 Vx1-2
ACH580-VxR-023A-4 23 15 R2 Vx1-2
ACH580-VxR-027A-4 27 20 R3 Vx1-3
ACH580-VxR-034A-4 34 25 R3 Vx1-3
ACH580-VxR-044A-4 44 30 R3 Vx1-3
ACH580-VxR-052A-4 52 40 R4 Vx1-4
ACH580-VxR-065A-4 65 50 R4 Vx1-4
ACH580-VxR-077A-4 77 60 R4 Vx1-4
1) “VxR” represents VCR and VDR.
