132 ACH580 E-Clipse bypass and packaged drive user manual
Embedded fieldbus
Multistate Value Objects
The following table summarizes the Multistate Value Objects supported
Loop Objects
The following table summarizes the Multistate Value Objects supported
BACnet Protocol Implementation Conformance Statement
For the BACnet Protocol Implementation Conformance Statement, please see ABB
document 3AXD10000768421.
Instance ID Object Name Description
MSV0 HAND AUTO REF This object indicates the drive’s Hand/Off/
Auto status.
MSV1 ACTIVE FAULT 1 This object indicates the drive’s most
recent fault.
MSV2 ACTIVE FAULT 2 This object indicates the drive’s second
most recent fault.
MSV3 ACTIVE FAULT 3 This object indicates the drive’s third most
recent fault.
MSV4 ACTIVE WARNING 1 This object indicates the drive’s most
recent warning.
MSV5 ACTIVE WARNING 2 This object indicates the drive’s second
most recent warning.
MSV6 ACTIVE WARNING 3 This object indicates the drive’s third most
recent warning.
Instance ID Object Name Description
LOOP0 LOOP SET 1 This object controls the drive’s first loop
object.
LOOP1 LOOP SET 2 This object controls the drive’s second
loop object.
