ABB aquamaster User Manual

Electronic Commercial Water Meter
AquaMaster™ 5 Specification
IM/AM Issue 13 39
5 Specification
Battery-powered Meters – Flow Requirements per ISO 4064 (Standard Version)
AC-powered Meters – Flow Requirements per ISO 4064 (Standard Version)
Size Qmax. N Q(0.5%) Qt Qmin.
mm in. m
3
/h (Ugal/min) m
3
/h (Ugal/min) m
3
/h (Ugal/min) m
3
/h (Ugal/min) m
3
/h (Ugal/min)
15 0.5 3 (13) 1.5 (7) 0.23 (1.0) 0.023 (0.099) 0.009 (0.040)
20 0.75 5 (22) 2.5 (11) 0.38 (1.7) 0.038 (0.165) 0.015 (0.066)
25 1.0 7 (31) 3.5 (15) 0.53 (2.3) 0.053 (0.23) 0.021 (0.09)
40 1.5 20 (88) 10 (44) 1.5 (6.6) 0.150 (0.66) 0.06 (0.26)
50 2 30 (132) 15 (66) 2.3 (9.9) 0.23 (1.0) 0.09 (0.40)
65 2.5 50 (220) 25 (110) 3.8 (16.5) 0.38 (1.7) 0.15 (0.66)
80 3 80 (352) 40 (176) 6 (26) 0.6 (2.6) 0.24 (1.06)
100 4 120 (528) 60 (264) 9 (40) 0.9 (4.0) 0.36 (1.59)
150 6 300 (1320) 150 (660) 23 (99) 2.3 (10) 0.9 (4.0)
200 8 500 (2200) 250 (1100) 38 (165) 3.8 (17) 1.5 (6.6)
250 10 800 (3520) 400 (1760) 60 (264) 6 (26) 2.4 (11)
300 12 1200 (5280) 600 (2640) 90 (400) 9 (40) 3.6 (16)
350 14 1600 (7040) 800 (3520) 120 (530) 25 (110) 10 (44)
400 16 2000 (8810) 1000 (4400) 150 (660) 31 (138) 13 (55)
450 18 2600 (11450) 1300 (5720) 195 (860) 44 (193) 18 (77)
500 20 3000 (13210) 1500 (6600) 225 (990) 63 (275) 25 (110)
600 24 5000 (22010) 2500 (11010) 375 (1650) 79 (347) 32 (139)
Size Qmax. N Q(0.5%) Qt Qmin.
mm in. m
3
/h (Ugal/min) m
3
/h (Ugal/min) m
3
/h (Ugal/min) m
3
/h (Ugal/min) m
3
/h (Ugal/min)
15 0.5 3 (13) 1.5 (7) 0.075 (0.33) 0.010 (0.044) 0.004 (0.018)
20 0.75 5 (22) 2.5 (11) 0.125 (0.55) 0.016 (0.069) 0.006 (0.028)
25 1.0 7 (31) 3.5 (15) 0.175 (0.77) 0.025 (0.11) 0.01 (0.04)
40 1.5 20 (88) 10 (44) 1.5 (6.6) 0.063 (0.28) 0.025 (0.11)
50 2 30 (132) 15 (66) 1.5 (6.6) 0.1 (0.4) 0.04 (0.18)
65 2.5 50 (220) 25 (110) 1.5 (6.6) 0.16 (0.7) 0.063 (0.28)
80 3 80 (352) 40 (176) 2 (8.8) 0.3 (1.1) 0.1 (0.44)
100 4 120 (528) 60 (264) 3(13) 0.4 (1.8) 0.16 (0.70)
150 6 300 (1320) 150 (660) 7.5 (33) 1 (4) 0.4 (1.8)
200 8 500 (2200) 250 (1100) 12.5 (55) 1.6 (7) 0.63 (2.8)
250 10 800 (3520) 400 (1760) 20 (88) 2.5 (11) 1 (4)
300 12 1200 (5280) 600 (2640) 30 (132) 4 (18) 1.6 (7)
350 14 1600 (7040) 800 (3520) 80 (352) 8 (35) 3.2 (14)
400 16 2000 (8810) 1000 (4400) 100 (440) 13 (55) 5 (22)
450 18 2600 (11450) 1300 (5720) 130 (572) 18 (77) 7 (31)
500 20 3000 (13210) 1500 (6600) 150 (660) 20 (88) 8 (35)
600 24 5000 (22010) 2500 (11010) 250 (1101) 32 (139) 13 (55)

ABB aquamaster Specifications

General

Type	Electromagnetic flowmeter
Power Supply	100 to 240 VAC, 24 VDC
Communication	HART, Modbus, Profibus
Ingress Protection	IP68
Temperature Range	-40°C to +70°C (-40 to +158 °F)
Applications	Water, wastewater
Lining material	rubber
Electrode material	Stainless steel, Hastelloy, Titanium
Protection Rating	IP67, IP68
Output Signals	4-20 mA, pulse, frequency
Storage Temperature	-40 to +70 °C (-40 to +158 °F)
Accuracy	±1 mm/s
Operating Temperature	-40°C to +60°C
Ambient Temperature	-40°C to +60°C
