High-speed counters,
CL-DC1, CL-DC2
119
1SVC 440 795 M0100
The example shows the counters C5 to C7 as retentive
counters.
The counter has the value 450 before the power supply is
switched off.
Figure 54: Retentive counter
a The numerical value 450 is retained even after a power outage.
U = Supply voltage of the device
High-speed counters,
CL-DC1, CL-DC2
The logic relay provides various high-speed counter
functions. These counter function blocks are coupled directly
to digital inputs. The following functions are possible:
• Frequency counters: C15 and C16
• High-speed counters: C13 and C14.
Frequency counter
The logic relay provides two frequency counters C15 and
C16 for use as required. The frequency counters can be used
for measuring frequencies. The high-speed frequency
counters are permanently connected to the digital inputs I3
and I4.
Applications such as speed monitoring, volume
measurement using a volume counter, the monitoring of
machine running can be implemented with the frequency
counter.
M 9 - M12 Æ
M13 - M16
N 9 - N16
C 5 - C 7 åæ
C 20
C13 - C16
T 02
T 8
T13 - T16
D 1 - D 8
Circuit diagram display Parameter settings of the counter C5
I6-------CC5
C5-------ÄQ3
I8-Q3----RC5
C5 N +
S 00565
U
햲햲
