Advanced status display
CL-LED display
CL-LSR.CX..., CL-LST.CX..., CL-LMR/CL-LMT, CL-LER and
CL-LET feature an LED on the front which indicates the status
of the power supply as well as the RUN or STOP mode
(a figure 2, Page 14).
Retention/debounce AC expansion ok/P buttons
Startup behaviour
RE
: Retention switched on
I
: Debounce switched on
AC
: AC expansion functioning correctly
DC
: DC expansion functioning correctly
GW
: Bus coupling module detected
GW flashing: Only CL-LEC.CI000 detected. I/O expansion not detected.
17.03.04 Display of actual device date
ST
: When the power supply is switched on, the logic relay switches to STOP mode
12...6.89...
RE I ACP-
17.03.04 ST
123.5.78 RUN
LED OFF No power supply
LED continuously
lit
Power supply present, STOP mode
LED flashing Power supply present, RUN mode
