Technical data
265
1SVC 440 795 M0100
Relay outputs
CL-LSR, CL-LMR, CL-LER.18AC2, CL-LER.18DC2,
CL-LER.2O
CL-LSR CL-LMR,
CL-LER.18AC2,
CL-LER.18DC2
CL-LER.2O
Quantity 4 6 2
Type of outputs
Relay
In groups of
1 1 2
Parallel switching of outputs to
increase performance
Not permissible
Protection of an output relay
Miniature circuit-breaker B16 or 8 A fuse (slow)
Potential isolation for mains current
supply, inputs
Yes
300 V AC (safe isolation)
600 V AC (basic isolation)
Mechanical lifespan
(switching operations)
10 x 10
6
Mains relays
Conventional therm. current 8 A (10 A UL)
Recommended for load
> 500 mA, 12 V AC/DC
Short-circuit resistance y = 1
16 A characteristic B (B16) at 600 A
Short-circuit resistance
y = 0.5 to 0.7
16 A characteristic B (B16) at 900 A
Rated impulse withstand voltage
U
imp
contact coil
4 kV
Rated insulation voltage Ui
Rated operational voltage Ue 250 V AC
Safe isolation to EN 50178 between
coil and contact
300 V AC
Safe isolation to EN 50178 between
two contacts
300 V AC
Making capacity
AC-15 250 V AC, 3 A (600 Ops/h) 300000 operations
DC-13 L/R F 150 ms 24 V DC,
1 A (500 Ops/h)
200000 operations
