CL settings
218
1SVC 440 795 M0100
Deactivating RUN mode
X Select RUN MODE å and press OK.
The RUN mode function is deactivated.
The default setting for the logic relay is for
RUN MODE å
to be displayed. In other words, starts in RUN mode when
the power is switched on.
Table 32: Startup behaviour
Behaviour when the circuit diagram is deleted
The startup mode setting is a CL device function. When the
circuit diagram is deleted this does not result in the loss of
the setting selected.
Behaviour during upload/download to memory
module or PC
When a valid circuit diagram is transferred from the logic
relay to a memory module or the PC or vice versa, the setting
is still retained.
Possible faults
The logic relay does not start in RUN mode:
• The logic relay does not have a program in it.
• You have selected STOP mode (RUN MODE menu).
DEBOUNCE åÆ
P BUTTONS
RUN MODE å
CARD MODE æ
Startup behaviour Menu displayed Status of the logic
relay after startup
The logic relay starts in
STOP mode
RUN MODE STOP mode
The logic relay starts in
RUN mode
RUN MODE å RUN mode
h
The CL models without a display can only be started in
RUN mode.
