Setting the menu language
65
1SVC 440 795 M0100
X Press OK.
The logic relay proposes the relay coil
Q1. The specified coil
function
Ä and the output relay Q1 are correct and do not
have to be changed.
Your first working CL circuit diagram now looks like this:
Press ESC to leave the circuit diagram display.
The adjacent menu will appear.
X Press OK.
The circuit diagram is now automatically saved. CANCEL
exits the circuit diagram. Changes that have been made to
the circuit diagram are not saved.
Once you have connected pushbutton actuators S1 and S2,
you can test your circuit diagram straight away.
Testing the circuit diagram
X Switch with ESC to the main menu and select the STOP
å RUN
menu option.
With
STOP RUN å and STOP å RUN you switch
to the RUN or STOP operating modes.
The CL is in RUN mode if the tick is present at the
corresponding menu item, i.e.
STOP RUN å.
I1-I2----ÄQ1
I1-I2----ÄQ1
SAVE
CANCEL
h
The logic relay saves all the necessary circuit diagram and
program data retentively in the internal data memory.
PROGRAM...Æ
STOP å RUN
PARAMETER..
INFO... æ
h
The tick next to a menu item indicates which operating
mode or function is currently active.
