CL operation
73
1SVC 440 795 M0100
Table 6: Contacts
Contact type
n/o n/c CL-LSR
CL-LST
CL-LMR
CL-LMT
Page
Analog value comparator function
relay
A a A1…A16 A1…A16 98
Counter function relay C c C1…C16 C1…C16 111
Text marker function relay D D1…D16 D1…D16 131
7-day time switch function relay Ö ö Ö1…Ö8 Ö1…Ö8 137
CL input terminal I i I1…I8 I1…I12 77
0 signal I13 I13
Expansion status – I14 236
Short-circuit/overload I16 I15…I16 236
Markers, (auxiliary relay) M m M1…M16 M1…M16 85
Markers (auxiliary relay) N N1…N16 N1…N16 85
Operating hours counter
O O1…O4 O1…O4 143
Cursor button P p P1…P4 P1…P4 82
CL output Q q Q1…Q4 Q1…Q8 77
Input terminal for expansion unit R – R1…R12 77
Short-circuit/overload with
expansion
R – R15…R16 236
CL output
(expansion or auxiliary marker S)
S S1…S8
(as marker)
S1…S8 85
Timer function relay
T t T1…T16 T1…T16 148
Jump label : – :1…:8 :1…:8 164
Year time switch
Y Y1…Y8 Y1…Y8 167
Master reset, (central reset) Z Z1…Z3 Z1…Z3 174
D
N
O
R
R
S
Y
Z
